LG · 55TR3DK, 65TR3DK, 75TR3DK, 86TR3DK, 98TR3DK
LG CreateBoard Interactive Digital Board
4K IPS touch board in 55 to 98 inch with 40-point touch, Android 13 EDLA, an OPS slot and LG ConnectedCare remote management.
Authorised Marketing PartnerISMS (Integrated Systems Management Services)
At a glance
- Sizes
- 55" · 65" · 75" · 86" · 98"55"65"75"86"98"
- Brightness
- 440 nits440 nits440 nits440 nits440 nits440 nits
- Resolution
- 3,840 × 2,160 (UHD)3,840 × 2,160 (UHD)3,840 × 2,160 (UHD)3,840 × 2,160 (UHD)3,840 × 2,160 (UHD)3,840 × 2,160 (UHD)
- Panel type
- IPS, direct backlightIPS, direct backlightIPS, direct backlightIPS, direct backlightIPS, direct backlightIPS, direct backlight
Specifications
From LG TR3DK (Education) datasheet, March 2026, and LG India product page 75TR3DK-I.
| Specification | 55" | 65" | 75" | 86" | 98" |
|---|---|---|---|---|---|
| Panel | |||||
| Resolution | 3,840 × 2,160 (UHD) | ||||
| Panel type | IPS, direct backlight | ||||
| Brightness | 440 nits | ||||
| Contrast ratio | 1,200 : 1 (dynamic 3,000 : 1) | ||||
| Haze | 25% | 25% | 25% | 28% | 25% |
| Viewing angle (H/V) | 178° / 178° | ||||
| Response time | 8 ms | ||||
| Operation hours | 16/7 | ||||
| Panel lifetime | 50,000 hours | ||||
| Touch | |||||
| Touch points | Max 40 (32 on Android) | ||||
| Glass | Toughened anti-glare, 9H (Mohs 7) | ||||
| Accuracy | ±1 mm | ||||
| Touch response | Under 5 ms | ||||
| Touch OS support | Windows, Linux, Mac, Android | ||||
| Android system | |||||
| Operating system | Android 13.0 (Google EDLA certified) | ||||
| Processor | Quad-core A55, Mali G52 MP2 | ||||
| RAM / storage | 8 GB / 64 GB | 4 GB / 32 GB | 4 GB / 32 GB | 8 GB / 64 GB | 8 GB / 64 GB |
| Wireless | Wi-Fi 6 (802.11ax), Bluetooth 5.0 | ||||
| LAN | Gigabit | ||||
| Connectivity | |||||
| Inputs | 3 × HDMI (HDCP 2.2), VGA, 4 × USB 3.0, 1 × USB 2.0, USB-C (power delivery, DP Alt), RS-232C, RJ45 | ||||
| Outputs | HDMI out, optical SPDIF, 2 × touch USB, RJ45 | ||||
| OPS | Slot with built-in OPS power | ||||
| Speakers | 15 W × 2 | ||||
| Software | |||||
| Screen sharing | LG CreateBoard Share | ||||
| Remote management | LG ConnectedCare (DMS licence sold separately) | ||||
| Other | PIP and PBP, Wake on LAN, booting logo, USB lock mode | ||||
| Physical and power | |||||
| Dimensions (W × H × D) | 1,271 × 774 × 87 mm | 1,488.4 × 896.6 × 87.2 mm | 1,709 × 1,020 × 88 mm | 1,957 × 1,160 × 100 mm | 2,244 × 1,323 × 91 mm |
| Weight | 26.1 kg | 35.0 kg | 47.3 kg | 58.6 kg | 103.6 kg |
| VESA mount | 400 × 200 mm | 600 × 400 mm | 800 × 600 mm | 800 × 600 mm | 800 × 600 mm |
| Power consumption (typical) | 170 W | 220 W | 225 W | 385 W | 395 W |
| Power consumption (max) | 395 W | 420 W | 430 W | 580 W | 610 W |
| Power supply | 100 to 240 V, 50/60 Hz, built in | ||||
Overview
The LG CreateBoard TR3DK is an interactive digital board for classrooms and meeting rooms: a 4K IPS panel behind 9H toughened anti-glare glass, 40-point touch that works with pens or fingers, and Android 13 with Google EDLA certification so Google apps run natively. An OPS slot and USB-C with power delivery bring a Windows PC or laptop onto the same screen, and CreateBoard Share handles wireless sharing from any device.
Fleets are monitored and controlled remotely with LG ConnectedCare, which reports status and pushes settings to every board on the network. Siddhi Global supplies the TR3DK in 55 to 98 inch through its ISMS (Integrated Systems Management Services) partnership, and can still source the earlier TR3DJ and TR3BF boards for schools standardising on an existing model.
Highlights
- 40-point touch on 9H toughened anti-glare glass
- Android 13 with Google EDLA certification for Google apps
- LG ConnectedCare remote monitoring and control
- LG CreateBoard Share wireless screen sharing
- OPS slot with built-in power for a Windows PC module
- USB-C with power delivery and front-facing ports
- 15 W × 2 speakers and a 440 nit 4K IPS panel
Variants
- TR3DK series (current)
- Android 13 with Google EDLA certification, 40-point touch, Wi-Fi 6 and an OPS slot, in 55 to 98 inch.
- TR3DJ series (legacy)
- Earlier UHD IPS CreateBoard on Android 8 with 20-point touch; still supplied on request.
- TR3BF series (legacy)
- UHD infrared-touch board with 20 touch points and 24 W speakers; still supplied on request.
Typical use
- Schools and classrooms
- Colleges and lecture halls
- Corporate meeting rooms and boardrooms
- Training and coaching centres
- Co-working and huddle spaces
- Design and planning studios
Quote for the LG CreateBoard Interactive Digital Board
Sizes, quantities and installation scoped on request, with a written quote from Kolkata.
